ZHB-3000A Fully Automatic Digital Brinell Hardness Tester

2018/1/18 13:53:12 reviews browses channel:News

At the beginning of 2018, Laihua has released its new product -- fully automatic digital Brinell hardness tester. Below please find its outstanding features.



Product features:

u Adopts casting shell with strong rigidity and precise structure design;

u Load of test force is controlled by the sensor, which makes the whole structure compact and loading of test force stable and exact.

u Test process is controlled by CPU, using automatic switching between the objective and the indenter. The location of switching adopts mechanical and electronic double matching, which enables precise positioning;

u With built-in panel computer, parameter setting is easy and results can be displayed direct; meanwhile, it also avoids the stimulation and visual fatigue caused by the light source of the eyepiece, thus reducing measuring error.

u After selecting the scale, the instrument can automatically select the indenter and objective; the test table rises automatically and then back to the focusing position after loading the test force; it shows a clear image of the indentation and automatically measures the indentation, which realizes the fully automation of the Brinell test.



Technical parameters:

Test Force:

62.5kgf, 100kgf, 125kgf, 187.5kgf, 250kgf, 500kgf, 750kgf, 1000kgf, 1500kgf, 3000kgf (kgf)

612.9N, 980.7N, 1226N, 1839N, 2452N, 4903N, 7355N, 9807N, 14710N, 29420N (N)

Test Range: 3.18653HBW

Loading Method: Automatic (Loading/Dwell/Unloading)

Hardness Reading: Indentation Displaying and Automatic Measuring on Touch Screen

Computer: CPU: Intel I5Memory: 2GSSD: 64G

CCD Pixel: 3.00 Million

Conversion Scale: HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBS, HBW

Data Output: USB Port, VGA Interface, Network Interface

Shifting between Objective and Indenter: Automatic Recognition and Shifting

Objective and Indenter: Three Indenters, Two Objectives

Objective: 1× 2×

Resolution: 3μm 1.5μm

Dwell Time: 0~95s

Max. Height of Specimen: 260mm

Throat: 150mm

Power Supply: AC220V, 50Hz

Executive Standard: ISO 6506ASTM E10-12JIS Z2243GB/T 231.2

Dimension: 700×380×1000mmPacking Dimension: 920×510×1280mm

Weight: Net Weight: 200kgGross Weight: 230kg



-->
